MSP430F1121AIRGER
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Ultra-Low-Power Microcontroller, 4kB Flash, 256B RAM, Comparator 24-VQFN -40 to 85
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 42105
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 880μm
Width 4mm
Length 4mm
Height 1mm
Technical
RAM (bytes) 256
Number of UART Channels 0
Integrated Cache NO
Format FIXED-POINT
Number of Programmable I/O 14
Low Power Mode YES
Boundary Scan YES
Density 32 kb
Number of Timers/Counters 1
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC NO
Access Time 8 μs
Watchdog Timer Yes
Data Converter Slope A/D
Bit Size 16
Program Memory Size 4KB 4K x 8 + 256B
Core Size 16-Bit
Program Memory Type FLASH
Peripherals POR, WDT
Core Processor MSP430
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 256 x 8
Number of I/O 14
Oscillator Type Internal
Memory Size 4kB
Interface UART
Power Supplies 2/3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 24
Frequency 8MHz
Supply Voltage 2.2V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series MSP430x1xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 43.204673mg
Number of Pins 24
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
