MSP430F110IPWR
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 16B Ultra-Lo-Pwr MCU 1kB FL 128B RAM Comp
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4149
≥1 USD $2.4149
≥10 USD $1.9817
≥100 USD $1.91995
≥500 USD $1.8582
≥1000 USD $1.7955
Inventory: 1515
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series MSP430x1xx
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 2.2V
Terminal Pitch 0.65mm
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Interface UART
Memory Size 1kB
Oscillator Type Internal
Number of I/O 14
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MSP430
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 1KB 1K x 8 + 128B
Supply Current-Max 0.35mA
Bit Size 16
Has ADC NO
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 576
RAM (bytes) 128
Dimensions
Length 6.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
