LM3S9997-IBZ80-C5T
RoHS
RoHS compliant
RoHS compliantPackage 108-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM Microcontrollers - MCU Stellaris Micro controller
PDF
/
Inventory: 3772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of UART Channels 3
Number of A/D Converters 2
Core Architecture ARM
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 32
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
Number of Bits 10
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.235V~1.365V
RAM Size 64K x 8
Number of I/O 60
Oscillator Type Internal
Memory Size 256kB
Interface CAN, Ethernet, I2C, IrDA, LIN, SPI, UART, USART, USB
Operating Supply Voltage 3.3V
Pin Count 108
Base Part Number LM3S9997
Frequency 80MHz
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 108
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e1
Series Stellaris? ARM? Cortex?-M3S 9000
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 108
Surface Mount YES
Package / Case 108-LFBGA
Mounting Type Surface Mount
