LM3S9792-IQC80-B1
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 128KB FLASH 100LQFP
PDF
/
Inventory: 9034
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Supplier Device Package 100-LQFP (14x14)
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series Stellaris? ARM? Cortex?-M3S 9000
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Frequency 80MHz
Base Part Number LM3S9792
Operating Supply Voltage 3.3V
Interface CAN, EBI/EMI, Ethernet, I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size 128kB
Oscillator Type Internal
Number of I/O 65
Speed 80MHz
RAM Size 64K x 8
Memory Type FLASH
Voltage - Supply (Vcc/Vdd) 1.235V~1.365V
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 128K x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, Microwire, QEI, SPI, SSI, UART/USART, USB OTG
Data Converter A/D 16x10b
Watchdog Timer Yes
Data Bus Width 32b
Number of Timers/Counters 4
Core Architecture ARM
Max Frequency 80MHz
Number of Programmable I/O 65
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
