LM3S818-IQN50-C2T
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM Microcontrollers - MCU IC ARM Cortex-M3 MCU 64K, Ext Temp
PDF
/
Buying Options
Total Price: USD $4.71
Unit Price: USD $4.710667
≥1 USD $4.710667
≥10 USD $4.444029
≥100 USD $4.192469
≥500 USD $3.955162
≥1000 USD $3.73129
Inventory: 1526
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7mm
Technical
Number of ADC Channels 1
Number of UART Channels 2
Number of Programmable I/O 30
Number of A/D Converters 1
Max Frequency 50MHz
Core Architecture ARM
Number of Timers/Counters 5
Data Bus Width 32b
Watchdog Timer Yes
Data Converter A/D 6x10b
Connectivity Microwire, QEI, SPI, SSI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
Number of Bits 10
Voltage - Supply (Vcc/Vdd) 3V~3.6V
Memory Type FLASH
RAM Size 8K x 8
Speed 50MHz
Number of I/O 30
Oscillator Type Internal
Memory Size 64kB
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Interface I2C, SPI, UART, USART
Operating Supply Voltage 3.3V
Base Part Number LM3S818
Frequency 50MHz
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series Stellaris? ARM? Cortex?-M3S 800
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 48-LQFP (7x7)
Number of Pins 48
Package / Case 48-LQFP
Mounting Type Surface Mount
