LM3S5R31-IBZ80-C3T
RoHS
RoHS compliant
RoHS compliantPackage 108-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 256KB FLASH 108BGA
PDF
/
Inventory: 6555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 108-LFBGA
Surface Mount YES
Number of Pins 108
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Stellaris? ARM? Cortex?-M3S 5000
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 108
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Frequency 80MHz
Base Part Number LM3S5R31
Pin Count 108
Operating Supply Voltage 3.3V
Interface CAN, EBI/EMI, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 67
RAM Size 48K x 8
Voltage - Supply (Vcc/Vdd) 1.08V~1.32V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Number of Bits 10
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity CANbus, EBI/EMI, I2C, IrDA, LINbus, Microwire, QEI, SPI, SSI, UART/USART, USB
Bit Size 32
Data Converter A/D 16x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
Core Architecture ARM
Number of A/D Converters 2
Number of UART Channels 3
Dimensions
Height Seated (Max) 1.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
