LM3S2412-EQC25-A2T
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 96KB FLASH 100LQFP
PDF
/
Inventory: 1627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series Stellaris? ARM? Cortex?-M3S 2000
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Tin (Sn)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 2.5V
Frequency 25MHz
Base Part Number LM3S2412
Pin Count 100
Operating Supply Voltage 3.3V
Interface CAN, I2C, IrDA, SPI, UART, USART
Memory Size 96kB
Oscillator Type Internal
Number of I/O 49
RAM Size 32K x 8
Voltage - Supply (Vcc/Vdd) 2.25V~2.75V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 10
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 96KB 96K x 8
Connectivity CANbus, I2C, IrDA, Microwire, SPI, SSI, UART/USART
Bit Size 32
Data Converter A/D 3x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 98304
Core Architecture ARM
Number of A/D Converters 1
Number of UART Channels 2
Dimensions
Length 14.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
