LM3S1Z16-IQR50-C5T
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 16KB FLASH 64LQFP
PDF
/
Inventory: 1459
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-LQFP
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Stellaris? ARM? Cortex?-M3S 1000
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 64
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 50MHz
Base Part Number LM3S1Z16
Pin Count 64
Supply Voltage-Min (Vsup) 3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 33
RAM Size 6K x 8
Voltage - Supply (Vcc/Vdd) 1.08V~1.32V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Number of Bits 10
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, IrDA, LINbus, Microwire, SPI, SSI, UART/USART
Bit Size 32
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
Core Architecture ARM
Number of A/D Converters 1
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
