LM3S1150-EQC50-A2
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 100LQFP
PDF
/
Inventory: 5408
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 14.2mm
Technical
Number of ADC Channels 0
Number of UART Channels 3
Core Architecture ARM
Number of Timers/Counters 6
PWM Channels YES
Data Bus Width 32b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Bit Size 32
Connectivity I2C, IrDA, Microwire, QEI, SPI, SSI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.25V~2.75V
RAM Size 16K x 8
Number of I/O 52
Oscillator Type Internal
Memory Size 64kB
Interface I2C, IrDA, SPI, UART, USART
Supply Voltage-Max (Vsup) 2.75V
Operating Supply Voltage 3.3V
Pin Count 100
Base Part Number LM3S1150
Frequency 50MHz
Supply Voltage 2.5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Series Stellaris? ARM? Cortex?-M3S 1000
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
