LF2402APGA-GREE
RoHS
RoHS compliant
RoHS compliantPackage 64-BQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 16KB FLASH 64QFP
PDF
/
Inventory: 7667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-BQFP
Number of Pins 64
Weight 1.764389g
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series C2000? C24x 16-Bit
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 64
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 1mm
Frequency 40MHz
Base Part Number LF2402
Pin Count 64
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Memory Size 16kB
Oscillator Type Internal
Number of I/O 21
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Core Processor C2xx DSP
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 16KB 8K x 16
Connectivity SCI
Supply Current-Max 110mA
Bit Size 16
Data Converter A/D 8x10b
Data Bus Width 16b
Address Bus Width 16
Boundary Scan YES
Low Power Mode YES
Format FIXED POINT
RAM (words) 544
Barrel Shifter YES
Internal Bus Architecture MULTIPLE
Dimensions
Height Seated (Max) 3.1mm
Length 20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
