F280041CPMS
RoHS
/
Package 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Non-RoHS Compliant GULL WING QUAD CMOS Microcontroller -40C~125C TJ 100MHz 1.6mm 100K x 8
PDF
/
Buying Options
Total Price: USD $7.41
Unit Price: USD $7.4096
≥1 USD $7.4096
≥10 USD $6.68976
≥100 USD $6.378944
≥500 USD $5.538834
≥1000 USD $5.289874
≥3000 USD $4.823113
Inventory: 446
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 64-LQFP
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tray
Series C2000? C28x Piccolo?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number F280041
Supply Voltage-Min (Vsup) 1.14V
Oscillator Type Internal
Number of I/O 26
Speed 100MHz
RAM Size 100K x 8
Voltage - Supply (Vcc/Vdd) 1.14V~1.32V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor C28x
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 128K x 8
Connectivity CANbus, I2C, LINbus, SCI, SPI, UART/USART
Bit Size 32
Data Converter A/D 14x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
ROM (words) 65536
Number of UART Channels 2
Dimensions
Height 1.6mm
Length 10mm
Width 10mm
Thickness 1.4mm
Compliance
RoHS Status Non-RoHS Compliant
