COP8SGE740N8
RoHS
/
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB OTP 40DIP
PDF
/
Buying Options
Total Price: USD $16.09
Unit Price: USD $16.09205
≥1 USD $16.09205
≥10 USD $13.20405
≥100 USD $12.79175
≥500 USD $12.3785
≥1000 USD $11.9662
Inventory: 1541
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 15.24mm
Length 52.235mm
Height Seated (Max) 5.334mm
Technical
ROM (words) 8192
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC NO
Access Time 15 μs
Bit Size 8
Supply Current-Max 6mA
Connectivity Microwire/Plus (SPI), UART/USART
Program Memory Size 8KB 8K x 8
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, PWM, WDT
Core Processor COP8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 256 x 8
Speed 15 MHz
Number of I/O 36
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number COP8SGE7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.5MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series COP8? 8SG
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 40
Surface Mount NO
Package / Case 40-DIP (0.600, 15.24mm)
Mounting Type Through Hole
