COP8SDR9HVA8
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 44PLCC
PDF
/
Buying Options
Total Price: USD $8.34
Unit Price: USD $8.3424
≥1 USD $8.3424
Inventory: 164
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Lead, Tin
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series COP8? 8S
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 220
Supply Voltage 4.5V
Terminal Pitch 1.27mm
Frequency 20MHz
Base Part Number COP8SDR9
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 37
Speed 2 MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor COP8
Peripherals POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 32K x 8
Connectivity Microwire/Plus (SPI), UART/USART
Supply Current-Max 14.7mA
Bit Size 8
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
Dimensions
Height Seated (Max) 4.57mm
Length 16.51mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
