COP8SAC740N9
RoHS
/
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 4KB OTP 40DIP
PDF
/
Buying Options
Total Price: USD $21.22
Unit Price: USD $21.22395
≥1 USD $21.22395
≥10 USD $17.41445
≥100 USD $16.87105
≥500 USD $16.3267
≥1000 USD $15.78235
Inventory: 1439
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Surface Mount NO
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Series COP8? 8SA
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Frequency 10MHz
Base Part Number COP8SAC7
Pin Count 40
JESD-30 Code R-PDIP-T40
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface SPI
Memory Size 4kB
Oscillator Type Internal
Number of I/O 36
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor COP8
Peripherals POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 4KB 4K x 8
Connectivity Microwire/Plus (SPI)
Bit Size 8
Access Time 10 μs
Has ADC NO
DMA Channels NO
PWM Channels YES
DAC Channels NO
Dimensions
Height Seated (Max) 5.334mm
Length 52.235mm
Width 15.24mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
