COP8CCR9LVA8
RoHS
/
Package 68-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Contains Lead Non-RoHS Compliant J BEND QUAD Microcontroller 20mus -40C~85C TA 20MHz 4.57mm
PDF
/
Buying Options
Total Price: USD $4.26
Unit Price: USD $4.2592
≥1 USD $4.2592
Inventory: 687
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 68-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series COP8? 8C
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 68
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Frequency 20MHz
Base Part Number COP8CCR9
Pin Count 68
JESD-30 Code S-PQCC-J68
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 59
Speed 2 MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor COP8
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 32K x 8
Connectivity Microwire/Plus (SPI), UART/USART
Bit Size 8
Data Converter A/D 16x10b
Access Time 20 μs
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
Dimensions
Height Seated (Max) 4.57mm
Length 25.13mm
Width 25.13mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
