UPSD3212A-40U6
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 80KB FLASH 80LQFP
PDF
/
Buying Options
Total Price: USD $19.84
Unit Price: USD $19.8417
≥1 USD $19.8417
≥10 USD $16.28015
≥100 USD $15.77095
≥500 USD $15.2627
≥1000 USD $14.7535
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 12mm
Height Seated (Max) 1.6mm
Technical
Address Bus Width 12
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 4x8b
Bit Size 8
Supply Current-Max 62mA
Connectivity I2C, UART/USART, USB
Program Memory Size 80KB 80K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals LVD, POR, PWM, WDT
Core Processor 8032
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
RAM Size 2K x 8
Number of I/O 46
Oscillator Type Internal
Memory Size 80kB
Interface I2C, UART, USART, USB
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Pin Count 80
Base Part Number UPSD32
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 40MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish MATTE TIN
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series μPSD
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 80
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
