STR711FR2H6
RoHS
RoHS compliant
RoHS compliantPackage 64-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM Microcontrollers - MCU 64-pin ARM7TDMI MCU 256KB ROM 16KB FLASH
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14605
≥1 USD $2.14605
≥10 USD $1.7613
≥100 USD $1.7062
≥500 USD $1.6511
≥1000 USD $1.596
Inventory: 1116
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-LFBGA
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STR7
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Frequency 66MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STR711
Pin Count 64
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Interface CAN, I2C, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 30
RAM Size 64K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM7?
Peripherals PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity HDLC, I2C, SmartCard, SPI, UART/USART, USB
Supply Current-Max 100mA
Bit Size 32
Data Converter A/D 4x12b
Watchdog Timer Yes
Access Time 66 μs
Has ADC YES
DMA Channels NO
Data Bus Width 32b
PWM Channels YES
ROM (words) 32768
Core Architecture ARM
On Chip Program ROM Width 32
Number of ADC Channels 4
Dimensions
Height Seated (Max) 1.7mm
Length 8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
