STM8S903F3M3
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20SO
PDF
/
Buying Options
Total Price: USD $8.79
Unit Price: USD $8.793074
≥1 USD $8.793074
≥10 USD $8.295352
≥100 USD $7.82581
≥500 USD $7.382832
≥1000 USD $6.96494
Inventory: 4546
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series STM8S
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Frequency 16MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM8S903
Pin Count 20
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 2.95V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 16
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.95V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor STM8
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 8K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 4.75mA
Bit Size 8
Data Converter A/D 5x10b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
ROM (words) 2048
EEPROM Size 640 x 8
On Chip Program ROM Width 32
Dimensions
Height Seated (Max) 2.65mm
Length 12.8mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
