STM8AF6223PDAX
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20TSSOP
PDF
/
Inventory: 5489
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series Automotive, AEC-Q100, STM8A
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 0.635mm
Frequency 16MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM8AF
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Power Supplies 3.3/5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 16
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor STM8A
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 8K x 8
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 4.75mA
Bit Size 8
Data Converter A/D 7x10b
ROM (words) 8192
EEPROM Size 640 x 8
Compliance
RoHS Status ROHS3 Compliant
