STM32L486QGI6TR
RoHS
RoHS compliant
RoHS compliantPackage 132-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 132UFBGA
PDF
/
Buying Options
Total Price: USD $10.61
Unit Price: USD $10.6128
≥1 USD $10.6128
≥10 USD $9.75568
≥100 USD $9.351584
≥500 USD $8.23944
≥1000 USD $7.835062
≥3000 USD $7.329573
Inventory: 1385
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.6mm
Technical
Number of DMA Channels 14
On Chip Data RAM Width 8
Number of External Interrupts 16
Number of Timers 16
RAM (words) 32000
Integrated Cache YES
Format FLOATING-POINT
External Data Bus Width 16
Low Power Mode YES
Boundary Scan YES
CPU Family CORTEX-M4
On Chip Program ROM Width 8
ROM (words) 1048576
Address Bus Width 26
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 19x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB OTG
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 48MHz
Peripherals Brown-out Detect/Reset, DMA, LCD, PWM, WDT
Core Processor ARM? Cortex?-M4
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.71V~3.6V
RAM Size 128K x 8
Speed 80MHz
Number of I/O 109
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.71V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PBGA-B132
Base Part Number STM32L486
Reach Compliance Code compliant
Terminal Pitch 0.5mm
Supply Voltage 3V
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
HTS Code 8542.31.00.01
ECCN Code 5A992.C
Number of Terminations 132
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series STM32L4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 132-UFBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
