STM32L041F6P7
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 32KB FLASH 20TSSOP
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.4992
≥1 USD $2.4992
≥10 USD $2.24488
≥100 USD $2.12256
≥500 USD $1.839534
≥1000 USD $1.745234
≥3000 USD $1.566004
Inventory: 1171
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.3mm
Length 6.5mm
Height Seated (Max) 1.2mm
Technical
Number of DMA Channels 7
Number of External Interrupts 26
Number of Timers 8
Integrated Cache NO
Format FIXED POINT
Low Power Mode YES
Boundary Scan NO
CPU Family CORTEX-M0
On Chip Program ROM Width 8
EEPROM Size 1K x 8
Core Architecture ARM
ROM (words) 32768
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 10x12b
Bit Size 32
Supply Current-Max 5.7mA
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor ARM? Cortex?-M0+
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 8K x 8
Number of I/O 15
Oscillator Type Internal
Memory Size 32kB
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-PDSO-G20
Base Part Number STM32L041
Frequency 32MHz
Terminal Pitch 0.65mm
Supply Voltage 3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
ECCN Code 5A992.C
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series STM32L0
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 10 Weeks
