STM32H757ZIY6TR
RoHS
/
Package 156-UFBGA, WLCSP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
HIGH-PERFORMANCE AND DSP WITH DP
PDF
/
Inventory: 9787
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width 4.64mm
Length 4.96mm
Technical
External Data Bus Width 16
Address Bus Width 26
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 23x16b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Program Memory Size 2MB 2M x 8
Core Size 32-Bit Dual-Core
Program Memory Type FLASH
Clock Frequency 50MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Core Processor ARM? Cortex?-M4, Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
RAM Size 1M x 8
Speed 240MHz, 480MHz
Number of I/O 99
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
Reach Compliance Code compliant
Terminal Pitch 0.35mm
Supply Voltage 3V
Terminal Form BALL
Terminal Position BOTTOM
Number of Terminations 156
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series STM32H7
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 156-UFBGA, WLCSP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
