STM32H745ZIT6
RoHS
/
Package 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
STM32 Series 2 MB Flash 1060 kB RAM 480 MHz 32-Bit Microcontroller - LQFP-144
PDF
/
Buying Options
Total Price: USD $16.39
Unit Price: USD $16.3856
≥1 USD $16.3856
≥10 USD $15.06208
≥100 USD $14.43743
≥500 USD $12.72055
≥1000 USD $12.096225
≥3000 USD $11.315832
Inventory: 633
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32H7
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.62V
Oscillator Type Internal
Number of I/O 97
Speed 240MHz, 480MHz
RAM Size 1M x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER RISC
Core Processor ARM? Cortex?-M4, Cortex?-M7
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Clock Frequency 48MHz
Program Memory Type FLASH
Core Size 32-Bit Dual-Core
Program Memory Size 2MB 2M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 23x16b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
Address Bus Width 12
External Data Bus Width 16
Dimensions
Length 20mm
Width 20mm
