STM32F779NIH6TR
RoHS
/
Package 216-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FLOATING-POINT GULL WING BOTTOM CMOS Microcontroller -40C~85C TA 281mA 26MHz 1.1mm
PDF
/
Buying Options
Total Price: USD $37.59
Unit Price: USD $37.5877
≥1 USD $37.5877
≥10 USD $30.8408
≥100 USD $29.8775
≥500 USD $28.91325
≥1000 USD $27.94995
Inventory: 1338
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 216-TFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series STM32F7
Part Status Active
Number of Terminations 216
Technology CMOS
Terminal Position BOTTOM
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Reach Compliance Code compliant
JESD-30 Code S-PBGA-B216
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.7V
Oscillator Type Internal
Number of I/O 159
Speed 216MHz
RAM Size 512K x 8
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M7
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Clock Frequency 26MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 2MB 2M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Supply Current-Max 281mA
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Address Bus Width 24
ROM (words) 2097152
On Chip Program ROM Width 8
CPU Family CORTEX-M7
Boundary Scan YES
Low Power Mode YES
External Data Bus Width 32
Format FLOATING-POINT
Integrated Cache YES
RAM (words) 512000
RAM (bytes) 524288
Number of Timers 15
Number of External Interrupts 16
On Chip Data RAM Width 8
Time-Min SECONDS
Number of DMA Channels 16
Dimensions
Height Seated (Max) 1.1mm
Length 13mm
Width 13mm
