STM32F767IIT6
RoHS
RoHS compliant
RoHS compliantPackage 176-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 2MB FLASH 176LQFP
PDF
/
Buying Options
Total Price: USD $17.83
Unit Price: USD $17.8288
≥1 USD $17.8288
≥10 USD $16.44456
≥100 USD $15.705888
≥500 USD $14.04282
≥1000 USD $13.396152
Inventory: 1309
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 24mm
Length 24mm
Height Seated (Max) 1.6mm
Technical
External Data Bus Width 32
On Chip Program ROM Width 8
ROM (words) 2097152
Address Bus Width 26
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 24x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Program Memory Size 2MB 2M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 26MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
RAM Size 512K x 8
Speed 216MHz
Number of I/O 140
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number STM32F767
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 176
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series STM32F7
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 176
Surface Mount YES
Package / Case 176-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
