STM32F733ZEI6
RoHS
RoHS compliant
RoHS compliantPackage 144-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 144BGA
PDF
/
Inventory: 5213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 144-UFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32F7
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
External Data Bus Width 16
Address Bus Width 26
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 16x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, UART/USART, USB
Program Memory Size 512KB 512K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 26MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
RAM Size 256K x 8
Speed 216MHz
Number of I/O 112
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number STM32F733
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.8mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Number of Terminations 144
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
