STM32F469AEH7
RoHS
/
Package 169-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
HIGH-PERFORMANCE ADVANCED LINE,
PDF
/
Inventory: 2107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 169-UFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Series STM32F4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 169
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.7V
Oscillator Type Internal
Number of I/O 114
Speed 180MHz
RAM Size 384K x 8
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M4
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Clock Frequency 26MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SAI, SDIO, SPI, UART/USART, USB, USB OTG
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
Address Bus Width 24
External Data Bus Width 32
Dimensions
Length 7mm
Width 7mm
