STM32F427IGH7
RoHS
RoHS compliant
RoHS compliantPackage 201-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 176UBGA
PDF
/
Buying Options
Total Price: USD $15.45
Unit Price: USD $15.4528
≥1 USD $15.4528
≥10 USD $14.20496
≥100 USD $13.616064
≥500 USD $11.996758
≥1000 USD $11.407968
≥3000 USD $10.671954
Inventory: 2068
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mounting Type Surface Mount
Package / Case 201-UFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series STM32F4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 176
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM32F427
JESD-30 Code S-PBGA-B176
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 140
Speed 180MHz
RAM Size 256K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M4
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency 50MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SPI, UART/USART, USB OTG
Supply Current-Max 135mA
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
ROM (words) 1048576
On Chip Program ROM Width 8
CPU Family CORTEX-M4
Dimensions
Height Seated (Max) 0.6mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
