STM32F423ZHT6
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1.5MB FLASH 144LQFP
PDF
/
Buying Options
Total Price: USD $12.36
Unit Price: USD $12.364
≥1 USD $12.364
≥10 USD $11.3652
≥100 USD $10.894048
≥500 USD $9.5986
≥1000 USD $9.127554
≥3000 USD $8.538675
Inventory: 210
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32F4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM32F423
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 114
Speed 100MHz
RAM Size 320K x 8
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M4
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Clock Frequency 26MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1.5MB 1.5M x 8
Connectivity CANbus, EBI/EMI, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 16x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
Dimensions
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
