STM32F302VCT6
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
STM32F Series 256 kB Flash 32 kB RAM ARM Based 32-Bit Microcontroller - LQFP-100
PDF
/
Buying Options
Total Price: USD $3.6
Unit Price: USD $3.60134
≥1 USD $3.60134
≥10 USD $3.39749
≥100 USD $3.20518
≥500 USD $3.02376
≥1000 USD $2.8526
≥3000 USD $2.69113
Inventory: 3430
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Gold, Tin
Mounting Type Surface Mount
Package / Case 100-LQFP
Surface Mount YES
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32F3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 72MHz
Base Part Number STM32F302
Supply Voltage-Min (Vsup) 2V
Interface CAN, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 87
RAM Size 40K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M4
Peripherals DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 17x12b; D/A 1x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
Number of Timers/Counters 8
Core Architecture ARM
CPU Family CORTEX-M4F
Number of ADC Channels 25
Number of PWM Channels 6
Number of I2C Channels 2
Number of SPI Channels 3
Number of USB Channels 1
Dimensions
Height 1.45mm
Length 14.2mm
Width 14.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
