STM32F217VET6TR
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-bit STM32F ARM Cortex M3 RISC 512KB Flash 2.5V/3.3V 100-Pin LQFP T/R
PDF
/
Buying Options
Total Price: USD $8.24
Unit Price: USD $8.2368
≥1 USD $8.2368
≥10 USD $7.56888
≥100 USD $7.255072
≥500 USD $6.90448
Inventory: 3986
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 1.6mm
Technical
Number of DMA Channels 2
Number of External Interrupts 16
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
CPU Family CORTEX-M3
On Chip Program ROM Width 8
Core Architecture ARM
ROM (words) 524288
Address Bus Width 8
Number of Timers/Counters 14
DAC Channels YES
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, Memory Card, SPI, UART/USART, USB OTG
Program Memory Size 512KB 512K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 132K x 8
Number of I/O 82
Oscillator Type Internal
Memory Size 512kB
Interface CAN, Ethernet, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 1.8V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 100
Base Part Number STM32F217
Frequency 120MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 434mW
HTS Code 8542.31.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code 5A992.C
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Series STM32F2
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 100
Surface Mount YES
Package / Case 100-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
