STM32F207ZET6TR
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 144LQFP
PDF
/
Buying Options
Total Price: USD $12.58
Unit Price: USD $12.5752
≥1 USD $12.5752
≥10 USD $11.55704
≥100 USD $11.078144
≥500 USD $9.760608
≥1000 USD $9.281571
Inventory: 1590
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Number of Pins 144
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series STM32F2
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code 3A991.A.2
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.31.00.01
Max Power Dissipation 500mW
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Terminal Pitch 0.5mm
Frequency 120MHz
Base Part Number STM32F207
Pin Count 144
Operating Supply Voltage 3.6V
Interface CAN, Ethernet, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 512kB
Oscillator Type Internal
Number of I/O 114
RAM Size 132K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, Memory Card, SPI, UART/USART, USB OTG
Supply Current-Max 93mA
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 14
Address Bus Width 24
ROM (words) 32768
Core Architecture ARM
On Chip Program ROM Width 128
CPU Family CORTEX-M3
Low Power Mode YES
Number of Serial I/Os 6
On Chip Data RAM Width 32
Number of DMA Channels 16
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
