STM32F103RGT6
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM Microcontrollers - MCU XL-Density Access Line 32-Bit 1G Flash
PDF
/
Buying Options
Total Price: USD $7.48
Unit Price: USD $7.48
≥1 USD $7.48
≥10 USD $6.87368
≥100 USD $6.589088
≥500 USD $6.270554
Inventory: 1558
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 10.2mm
Length 10.2mm
Height 1.45mm
Technical
Number of USB Channels 1
Number of SPI Channels 3
Number of I2C Channels 2
Number of ADC Channels 16
Number of Programmable I/O 112
Core Architecture ARM
Number of Timers/Counters 14
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b; D/A 2x12b
Bit Size 32
Supply Current-Max 68mA
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Core Processor ARM? Cortex?-M3
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~3.6V
RAM Size 96K x 8
Number of I/O 51
Oscillator Type Internal
Memory Size 1MB
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2V
Pin Count 64
Base Part Number STM32F103
Time@Peak Reflow Temperature-Max (s) 30
Frequency 72MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Series STM32F1
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 10 Weeks
