STM32F100C6T6B
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-bit STM32F1 ARM Cortex M3 RISC 32KB Flash 2.5V/3.3V 48-Pin LQFP Tray
PDF
/
Buying Options
Total Price: USD $3.95
Unit Price: USD $3.9512
≥1 USD $3.9512
≥10 USD $3.5508
≥100 USD $3.357024
≥500 USD $2.9095
≥1000 USD $2.760243
≥3000 USD $2.47676
Inventory: 1117
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 48-LQFP
Surface Mount YES
Number of Pins 48
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series STM32F1
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Max Power Dissipation 363mW
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 24MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STM32F100
Pin Count 48
Supply Voltage-Min (Vsup) 2.4V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 37
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 32KB 32K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 32
Data Converter A/D 10x12b; D/A 2x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
Number of Timers/Counters 5
Core Architecture ARM
CPU Family CORTEX-M3
Number of ADC Channels 10
Number of PWM Channels 6
Number of I2C Channels 1
Dimensions
Height 1.45mm
Length 7.2mm
Width 7.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
