STM32F058R8T6
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 64LQFP
PDF
/
Buying Options
Total Price: USD $3.97
Unit Price: USD $3.9688
≥1 USD $3.9688
≥10 USD $3.56136
≥100 USD $3.366528
≥500 USD $2.917587
≥1000 USD $2.767987
≥3000 USD $2.483712
Inventory: 1242
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 10mm
Technical
Core Architecture ARM
Number of Timers/Counters 8
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 19x12b; D/A 1x12b
Bit Size 32
Connectivity HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M0
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.65V~3.6V
RAM Size 8K x 8
Number of I/O 54
Oscillator Type Internal
Memory Size 64kB
Interface HDMI, I2C, I2S, IrDA, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 1.65V
Supply Voltage-Max (Vsup) 1.95V
Base Part Number STM32F05
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 444mW
ECCN Code 3A991.A.2
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series STM32F0
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 10 Weeks
