STM32F051R8H7
RoHS
RoHS compliant
RoHS compliantPackage 64-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 64UFBGA
PDF
/
Inventory: 7170
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 64-UFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series STM32F0
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 48MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STM32F05
JESD-30 Code S-PBGA-B64
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2V
Interface HDMI, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 55
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M0
Peripherals DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 64K x 8
Connectivity HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 32
Data Converter A/D 19x12b; D/A 1x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Core Architecture ARM
Dimensions
Height Seated (Max) 0.6mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
