STM32F042K6U7
RoHS
RoHS compliant
RoHS compliantPackage 32-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant QUAD CMOS Surface Mount Microcontroller 526mW -40C~105C TA 48MHz 5mm
PDF
/
Inventory: 6899
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 32-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Series STM32F0
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Max Power Dissipation 526mW
Technology CMOS
Terminal Position QUAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 48MHz
Base Part Number STM32F04
JESD-30 Code S-XQCC-N32
Power Supplies 2.5/3.3V
Supply Voltage-Min (Vsup) 2V
Interface CAN, HDMI, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 32kB
Oscillator Type Internal
Number of I/O 26
RAM Size 6K x 8
Voltage - Supply (Vcc/Vdd) 1.65V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M0
Peripherals DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 32KB 32K x 8
Connectivity CANbus, HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 13x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 6
Core Architecture ARM
On Chip Program ROM Width 8
CPU Family CORTEX-M0
Number of Programmable I/O 28
Dimensions
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
