STM32F042C6T6TR
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 32KB FLASH 48LQFP
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.4848
≥1 USD $3.4848
≥10 USD $3.13368
≥100 USD $2.96208
≥500 USD $2.567136
≥1000 USD $2.435523
≥3000 USD $2.185374
Inventory: 562
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1.6mm
Technical
On Chip Program ROM Width 8
Core Architecture ARM
ROM (words) 32768
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 13x12b
Bit Size 32
Connectivity CANbus, HDMI-CEC, I2C, IrDA, LINbus, SPI, UART/USART, USB
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M0
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.65V~3.6V
RAM Size 6K x 8
Number of I/O 38
Oscillator Type Internal
Memory Size 32kB
Interface CAN, HDMI, I2C, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G48
Base Part Number STM32F04
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
ECCN Code 3A991.A.2
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series STM32F0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 48-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
