ST7FLITE35F2M6
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit ST7 ST7 CISC 8KB Flash 3.3V/5V 20-Pin SO Tube
PDF
/
Buying Options
Total Price: USD $2.74
Unit Price: USD $2.7436
≥1 USD $2.7436
≥10 USD $2.2515
≥100 USD $2.1812
≥500 USD $2.1109
≥1000 USD $2.0406
Inventory: 1473
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status NRND (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series ST7
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Microcontrollers
Max Power Dissipation 330mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) 30
Number of SPI Channels 1
Number of PWM Channels 4
Number of ADC Channels 7
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 7x10b
Bit Size 8
Connectivity LINbusSCI, SPI
Program Memory Size 8KB 8K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 384 x 8
Number of I/O 15
Oscillator Type Internal
Memory Size 8kB
Interface SCI, SPI
Supply Voltage-Min (Vsup) 3.3V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 20
Base Part Number ST7FL
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.6mm
Length 13mm
Height 2.35mm
