ST7FLITE30F2M6
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20SOIC
PDF
/
Inventory: 2300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 12.8mm
Height Seated (Max) 2.65mm
Technical
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 7x10b
Bit Size 8
Connectivity LINbusSCI, SPI
Program Memory Size 8KB 8K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 384 x 8
Number of I/O 15
Oscillator Type External
Memory Size 8kB
Interface SPI
Supply Voltage-Min (Vsup) 3.3V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Base Part Number ST7FL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 16MHz
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Additional Feature ALSO OPERATES 2.7V MINIMUM SUPPLY AT 8 MHZ
Terminal Finish MATTE TIN
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series ST7
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
