ST7FLITE10F1B6
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Buying Options
Total Price: USD $16.35
Unit Price: USD $16.3533
≥1 USD $16.3533
≥10 USD $13.4178
≥100 USD $12.99885
≥500 USD $12.5799
≥1000 USD $12.16
Inventory: 4607
Minimum: 1
-
+
Technical Details
Physical
Package / Case PDIP
Surface Mount NO
Number of Pins 20
Technical
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 8MHz
Pin Count 20
Temperature Grade INDUSTRIAL
Interface SPI
Max Supply Voltage 5.5V
Min Supply Voltage 2.4V
Memory Size 4kB
Power Dissipation-Max 500mW
Number of I/O 15
Speed 16 MHz
RAM Size 256B
Memory Type FLASH
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Number of Bits 8
Supply Current-Max 12mA
Bit Size 8
Frequency (Max) 8MHz
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 8
CPU Family ST72
Number of Programmable I/O 15
RAM (bytes) 256
Dimensions
Length 26.16mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
