ST72F651AR6T1
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU Flash 32K USB/SPI
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1847
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 15
ROM (words) 32768
Number of Timers/Counters 1
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 8x8b
Bit Size 8
Supply Current-Max 20mA
Connectivity I2C, SPI, USB
Program Memory Size 32KB 32K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals DMA, LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 4V~5.5V
RAM Size 5K x 8
Speed 8 MHz
Number of I/O 47
Oscillator Type External
Memory Size 32kB
Interface I2C, SPI, USB
Supply Voltage-Min (Vsup) 4V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 64
Base Part Number ST72F65
Time@Peak Reflow Temperature-Max (s) 30
Frequency 12MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 500mW
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series ST7
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 64
Package / Case 64-LQFP
Mounting Type Surface Mount
Mount Surface Mount
