ST72F561J9TCXS
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Buying Options
Total Price: USD $6.99
Unit Price: USD $6.990271
≥1 USD $6.990271
≥10 USD $6.594591
≥100 USD $6.221314
≥500 USD $5.869164
≥1000 USD $5.536946
Inventory: 6394
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
ROM Programmability FLASH
RAM (bytes) 2048
CPU Family ST72
On Chip Program ROM Width 8
ROM (words) 61440
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Bit Size 8
Supply Current-Max 15mA
Clock Frequency 16MHz
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Speed 8 MHz
Number of I/O 34
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade AUTOMOTIVE
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G44
Pin Count 44
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3
Part Status Active
JESD-609 Code e3
Published 2011
Physical
Surface Mount YES
Supply Chain
Factory Lead Time 17 Weeks
