ST72F561J6T6
RoHS
RoHS compliant
RoHS compliantPackage 44-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU ST72561 8B MCU
PDF
/
Buying Options
Total Price: USD $26.85
Unit Price: USD $26.84795
≥1 USD $26.84795
≥10 USD $22.02955
≥100 USD $21.3408
≥500 USD $20.653
≥1000 USD $19.96425
Inventory: 40
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-LQFP
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series ST7
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 500mW
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ST72F56
Pin Count 44
Operating Supply Voltage 5V
Power Supplies 5V
Interface CAN, SCI, SPI
Memory Size 32kB
Oscillator Type External
Number of I/O 32
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 3.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 32K x 8
Connectivity CANbus, LINbusSCI, SPI
Supply Current-Max 150mA
Bit Size 8
Data Converter A/D 11x10b
Access Time 8 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Number of Programmable I/O 48
Dimensions
Height Seated (Max) 1.6mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
