ST72F561J4TAE
RoHS
RoHS compliant
RoHS compliantPackage 44-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 8B MCU
PDF
/
Inventory: 4497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.6mm
Technical
Number of Programmable I/O 48
On Chip Program ROM Width 8
ROM (words) 16384
Number of Timers/Counters 2
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 11x10b
Bit Size 8
Supply Current-Max 15mA
Connectivity CANbus, LINbusSCI, SPI
Program Memory Size 16KB 16K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3.8V~5.5V
RAM Size 1K x 8
Number of I/O 32
Oscillator Type External
Memory Size 16kB
Interface CAN, SCI, SPI
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 44
Base Part Number ST72F56
Frequency 8MHz
Terminal Pitch 0.8mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 500mW
Subcategory Microcontrollers
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series ST7
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Package / Case 44-LQFP
Mounting Type Surface Mount
Mount Surface Mount
