ST72F324K6TA
RoHS
RoHS compliant
RoHS compliantPackage 32-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 32LQFP
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 1238
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7mm
Height Seated (Max) 1.6mm
Technical
Number of Timers/Counters 2
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Connectivity SCI, SPI
Program Memory Size 32KB 32K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals LVD, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3.8V~5.5V
RAM Size 1K x 8
Number of I/O 24
Oscillator Type Internal
Memory Size 32kB
Interface SCI, SPI
Supply Voltage-Min (Vsup) 3.8V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 32
Base Part Number ST72F32
Frequency 8MHz
Terminal Pitch 0.8mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Max Power Dissipation 500mW
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series ST7
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-LQFP
Mounting Type Surface Mount
