ST72F324K6B6
RoHS
RoHS compliant
RoHS compliantPackage 32-SDIP (0.400, 10.16mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 32KB FLASH 32SDIP
PDF
/
Inventory: 8481
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 32-SDIP (0.400, 10.16mm)
Surface Mount NO
Number of Pins 32
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series ST7
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Power Dissipation 500mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 1.778mm
Frequency 8MHz
Base Part Number ST72F32
Pin Count 32
Operating Supply Voltage 5V
Interface SCI, SPI
Memory Size 32kB
Oscillator Type Internal
Number of I/O 24
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 3.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 32K x 8
Connectivity SCI, SPI
Bit Size 8
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
On Chip Program ROM Width 8
Dimensions
Height Seated (Max) 5.08mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
