ST72E331J4D0
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 7980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case CDIP
Surface Mount NO
Number of Pins 42
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Number of Terminations 42
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Microcontrollers
Technology HCMOS
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Supply Voltage 5V
Terminal Pitch 1.778mm
Pin Count 42
Interface SCI, SPI
Max Supply Voltage 5.5V
Min Supply Voltage 3.5V
Memory Size 16kB
Number of I/O 32
RAM Size 512B
Memory Type EPROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Bit Size 8
Frequency (Max) 8MHz
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
ROM (words) 16384
On Chip Program ROM Width 8
Number of Programmable I/O 32
RAM (bytes) 512
ROM Programmability UVPROM
Dimensions
Height Seated (Max) 4.01mm
Length 37.34mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
