ST62T55CN6
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 6778
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SSOP
Surface Mount YES
Number of Pins 28
Technical
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 3
Number of Terminations 28
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES AT 3V MINIMUM SUPPLY
Subcategory Microcontrollers
Technology HCMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 4V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 28
Power Supplies 3.3/5V
Temperature Grade INDUSTRIAL
Interface SCI
Max Supply Voltage 6V
Min Supply Voltage 3V
Memory Size 3.8kB
Number of I/O 21
RAM Size 128B
Memory Type EPROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Supply Current-Max 7mA
Bit Size 8
Frequency (Max) 8MHz
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 3884
CPU Family ST6200
Number of Programmable I/O 21
RAM (bytes) 128
ROM Programmability OTPROM
Dimensions
Height Seated (Max) 2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
