SPC56EL54L3CBFSY
RoHS
/
Package 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Non-RoHS Compliant GULL WING QUAD CMOS Microcontroller 3.3V -40C~125C TA 311.6mA 40MHz
PDF
/
Inventory: 8131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 100-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Series Automotive, AEC-Q100, SPC56xL
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
ECCN Code 3A991.A.2
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SPC56E
JESD-30 Code S-PQFP-G100
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.63V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Oscillator Type Internal
Number of I/O 16
Speed 120MHz
RAM Size 96K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.63V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor e200z4d
Peripherals DMA, LVD, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 32-Bit Dual-Core
Program Memory Size 768KB 768K x 8
Connectivity CANbus, LINbus, SCI, SPI, UART/USART
Supply Current-Max 311.6mA
Bit Size 32
Data Converter A/D 32x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
Address Bus Width 32
ROM (words) 786432
External Data Bus Width 64
Dimensions
Length 14mm
Width 14mm
Compliance
RoHS Status Non-RoHS Compliant
